TCR-1000-CH Cross Hauling Air Hoist

The Red Rooster Lifting TCR series of air hoists offers a comprehensive range of lifting equipment suited to all types of industrial and marine environments. Red Rooster Lifting hoists are the perfect lifting solution for where the duty is high, or where a robust hoist is required to withstand harsh conditions. The hoists comply with the UK supply of Machinery (Safety) Regulations 2008 and the European Machinery Directive. The hoists can be UKCA Marked or CE marked.

This model of air hoist is suitable for ‘Cross Hauling’ working fully loaded at angles of up to 45 degrees from the vertical. It can be used for positioning and transferring loads with the load chains under tension between hoists (see Diagram 1). The safety factor built into the hoist means that the weight of the load being lifted/transferred will not cause either hoist to be overloaded during operation. Where modified for cross hauling at up to 45 degree angle the model number will end with ‘CH’.

When carrying out complex lifting operations like cross hauling to transfer loads from one hoist to another a formal work pack should be in place including a lift plan, method statement and a risk assessment completed by a competent person.

The hoist manual contains further details on safe operation while cross hauling, fleeting or oblique or non-vertical lifting and pulling using Red Rooster air hoists.

For further information please contact Red Rooster Lifting.

STANDARD FEATURES

• Toku rotary vane motor
• ATEX zone 2 specification
• Robust epicycle gearbox
• Failsafe automatic internal disc brake
• Mechanical upper & lower switches
• Cast steel housing
• Internal silencing down to 83 dB(A)
• Alloy safety swivel hooks with safety catch
• Load chain 7.1 x 21mm of European manufacture to EN818-7
• Automatic load limiter

AVAILABLE OPTIONS

• Cross hauling up to 45 degrees
• Marine specification
• Special paint systems
• Corrosion protection
• ATEX zone 1 specification
• Chain collectors* (PVC, galvanised or stainless steel)
• Air service units
• Radio control*
• Main air shut off valve

*Please contact us for cross hauling applications.

This product (specification may vary) is available for rental. Explore our hire section for more information or talk to one of our team to discuss rental options.

Other products in the TCR Air Hoists range:

• TCR-250 Hook Suspension Mini Air Hoist
• TCR-250ME Hook Suspension Air Hoist
• TCR-500 Hook Suspension Air Hoist
• TCR-500/2 Hook Suspension Mini Air Hoist
• TCR-1000/2 Hook Suspension Air Hoist
• TCR-2000/2 Hook Suspension Air Hoist

Can’t see what you’re looking for? Explore all of our Hook Suspension Air Hoists or get in touch to discuss your lifting project with a member of our lifting team.

TCR-1000 Rental

There is a rental version of the TCR-1000 available. Download the Rental Datasheet (below the product image) for more information or speak to our team today to get started with your rental.
